DesignJet 750CPlus (D-size)
HP Parts Reference Guide™
Paper and Other Media
Vellum
C3864A Vellum (75 gsm) - D size (22 x 34-inches), 20 lb, 3.0 mil - 100 sheets
NO LONGER SUPPLIED
C3862A Vellum - 61cm (24in) x 45.7m (150ft) roll
C3866A Vellum (75 gsm) - Architectural D size (24 x 36-inches), 20 lb, 3.0 mil - 100 sheets
NO LONGER SUPPLIED
C3862A New Part for C3866A
Pincharm Assembly Parts
Bushing
260
C1633-40082 Pincharm spring retaining bushing
Cam
261
C2847-20005 Pinch arm bar cam (D-size) - Long rod from left to right side of printer - Used to lift the pinch arms
Lift Assembly
262
C3195-60116 Pincharm lift assembly - Does NOT include pincharm bar cam - Includes pinchwheel manual lift handle, spring, sensor,
rocker plate, cam drive, cam journals, wire linkages, nuts, screws, and washer
Pincharm
263
C4705-60091 Pincharm assembly - Curved black plastic plate with 4 small rollers (Does NOT include spring or bushing)
Spring
264
C1633-80005 Compression spring between pincharm assembly and bushing
Roll Feed Parts
Brake/Housing
265
C4704-60199 Brake/housing assembly (on right side) - Accepts the flange end of the spindle rod assembly - Includes the 2 housing
pieces, 2 brake shoes, brake gear, brake lever, and springs
Cover
266
C4705-60084 Rollfeed access cover - Opens forward to allow access to paper spindle assembly - Includes cover and springs
End Cap
267
C2858-40043 Spindle end cap (small) (or core spacer) - Removes for loading the media roll
268
C3172-40006 Spindle end cap (large)
Housing
269
C4704-60082 Housing assembly (on left side)
Spindle Kit
270
C2847-60093 Rollfeed spindle rod assembly (D-size) - Includes spindle and end caps
271
C3172-60003 Rollfeed spindle rod assembly (D-size) - Includes spindle and end caps - Special unit for use in China
272
C3172A D/A1 rollfeed spindle rod assembly for DesignJet 6xx/7xx - Includes spindle and end caps
