1 Check mark icon: Indicates that the photo has been selected for printing.
2 Page layout icon: Indicates the page layout selected.
3 Paper icon: Flashes when the printer is out of paper or there is a paper jam.
4 Pen icons: Represent the cartridges in each chute. The icons appear when the cartridges are
installed. The bars next to each pen icon indicate the approximate ink levels in each cartridge.
5 Copies icon: Indicates the number of copies to be printed. No icon is present when only one
copy is to be printed.
6 Image number icon: Indicates the number of the image on the memory card. It also indicates
the presence of Digital Print Order Format (DPOF).
HP Photosmart D5100 series User Guide 7
