Item Description Status
Flashing blue = System is being managed
remotely.
Off = Off
2 NIC/Lights-Out
100 link
Green or flashing green = 10M/100M link
speed
Amber = 1-GB link speed
Off = No connection
3 NIC/Lights-Out
100 activity
Green = Linked to the network
Flashing green = Linked and activity on the
network
Off = No network activity
PCI expansion slot definitions
Slot Type Length Connector Interconnect
1 PCIe2 Full x16 x16
1 Optional PCI-X Full 133 MHz/3.3 V 64 bit
2 PCIe Half x16 x4
System board components
Item Description
1 DIMM slots (6)
2 24-pin ATX system board power connector
3 Processor fan 1 cable connector
4 Processor fan 2 cable connector
5 Processor fan 3 cable connector
Component identification 9
