240
Chapter 13 LineJet Print Server Naming Schemes
Web Browser
1. Using a Web browser, direct the browser to URL
http://
LineJetIPaddress
/destConf.html
(e.g.,
http://192.75.11.9/destConf.html)
2. At the “Print Path Configuration” HTML form that displays, select a
destination link (e.g., d1prn) from the top of the page to bring up the
appropriate destination form.
3. Once the desired destination HTML form displays, scroll down to the
“Logpath Type” and “Logpath Port” sections to view the current logpath
settings for this particular destination.
Whether using Telnet or a Web browser, you can alter any of these settings at
this point and then click on the SUBMIT button to store them into the LineJet
Print Server. Remember to repower the LineJet Print Server to make the
settings take effect.
LineJet Print Server Naming Schemes
Figure 17. LineJet Print Server Default Names
Note If prompted for a User ID and password first, type in
root for the ID and
press ENTER at the password prompt since there is no password by
default.
Note If prompted for a User ID and password first, type in root for the ID and
press ENTER at the password prompt since there is no password by
default.
I/O PORT DESTINATION MODEL LOGPATH
d1prn
d4prn
d3prn
d2prn
m1
m2
m3
m4
l1
l2
l3
l4
PRN
