Decoder (EXT-2)
You can use this mode to connect any de-
coder to your TV.
Press the
or buttons to set it On or
Off.
When you select Decoder (EXT-2) On, EXT-2
output will be chosen as TV mode only and
any scrambled channels will be unscrambled
through decoder connected your TV via EXT-2
output.
Setting VCR ( Video Cassette Recorder )
Mode
This item can be seen in TV, EXT-1, EXT-2,
EXT-2S, EXT-3, EXT-4 and EXT-4S modes.
If you want to watch a VCR source from one
of these modes, then it will be better to set
VCR mode On. For this, while the cursor is
on this item press the
or buttons to
set it On.
If you want to watch a DVD, then you must set
this item off; because DVD is not a source
like a VCR and to see the picture better, you
must set the VCR mode Off.
To Store Settings
Press / or OK button on Store op-
tion to store Install menu settings.
After stored, T-V LINK menu will appear. If
you do not need to do T-V LINK, select Can-
cel and press
or OK button to exit the
menu.
Program Menu
Press "MENU" button, now you are in main
menu. In the main menu, select Program
using or button. Then enter the
Programme menu by pressing
/ or
OK button.
Note: There is no Program menu in any EXT
modes.
Program Menu is used to delete a channel, to
change the programme number of a channel,
to give a channel name to a channel, and to
start the A.P.S (Autostore) function.
To choose a channel in the PROGRAM
menu
Press
/ / / button. The
programme number that you choose is high-
lighted in the Program.
Caution:
Using Delete or Insert function rewrite the current chan-
nel list in the Program menu. Therefore, the programme num-
bers of some of channels will change.
When you complete the settings of
Program menu:
If you have a T-V LINK compatible VCR, press
button to display the T-V LINK menu. then
follow the operating procedure Downloading
the data to VCR.
If you do not have a T-V LINK compatible VCR,
select Cancel and press
or OK button to
exit the menu.
To give a channel name (Name):
1. Choose the channel you want to give a chan-
nel name.
2. Press the RED button to enter the Name
mode.
3. Press or button to choose the
position,and press or button to
