NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
57
POS.
NO
VERS.
COLOR
PART NO.
(FOR EUR)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR EUR)
DESCRIPTION
PART NO.
(MJI)
R348 nsp CHIP 100
Ω
±5% 1/16W NN05101610
R349 nsp CHIP 0
Ω
±5% 1/16W NN05000610
R350 nsp CHIP 10
Ω
±5% 1/16W NN05100610
R351 nsp CHIP 22k
Ω
±5% 1/16W NN05223610
R354
nsp CHIP 47
Ω
±5% 1/16W NN05470610
R361
R371 nsp CHIP 10k
Ω
±5% 1/16W NN05103610
R372 nsp CHIP 100k
Ω
±5% 1/16W NN05104610
R373 nsp CHIP 68k
Ω
±5% 1/16W NN05683610
R377 NP05224610 CHIP 220k
Ω
±5% 1/16W NP05224610
R378 nsp CHIP 68k
Ω
±5% 1/16W NN05683610
RF01 nsp CHIP 1k
Ω
±5% 1/16W NN05102610
RF02 nsp CHIP 330k
Ω
±5% 1/16W NN05334610
RF03
nsp CHIP 47k
Ω
±5% 1/16W NN05473610
RF06
RF07 nsp CHIP 4.7k
Ω
±5% 1/16W NN05472610
RF08 nsp CHIP 100k
Ω
±5% 1/16W NN05104610
RF09 nsp CHIP 10k
Ω
±5% 1/16W NN05103610
RF10 nsp CHIP 100k
Ω
±5% 1/16W NN05104610
RF12 nsp CHIP 4.7k
Ω
±5% 1/16W NN05472610
RF13 nsp CHIP 0
Ω
±5% 1/16W NN05000610
RF14
nsp CHIP 47k
Ω
±5% 1/16W NN05473610
RF18
RF19 nsp CHIP 0
Ω
±5% 1/16W NN05000610
RF20 nsp CHIP 47k
Ω
±5% 1/16W NN05473610
RF21 nsp CHIP 10k
Ω
±5% 1/16W NN05103610
RF22 nsp CHIP 10k
Ω
±5% 1/16W NN05103610
RF23 nsp CHIP 10k
Ω
±5% 1/16W NN05103610
PV16-SEMICONDUCTORS
D104
HZ21005000 CHIP DIODE HZ21005000
D106 1SS301 DAN202U UMT
D109 HZ20003100 CHIP DIODE DIODE
EC105DS2TE12L
HZ20003100
Q101 HC10077250 IC CXD1881R RF AMP HC10077250
Q102 HC10147090 IC NJM2115V OP-AMP HC10147090
Q103 HX207982A0 CHIP TRS 2SB798 DL DK HX207982A0
Q104 HX207982A0 CHIP TRS 2SB798 DL DK HX207982A0
Q105 HX207982A0 CHIP TRS 2SB798 DL DK HX207982A0
Q106 HC12239090 IC NJM3414AV OP-AMP SSOP8P HC12239090
Q107 HF230192A0 F.E.T. 2SK3019 FET SWICTHING HF230192A0
Q108 HF230192A0 F.E.T. 2SK3019 FET SWICTHING HF230192A0
Q109 HC12237090 IC NJM2137V OP-AMP HC12237090
Q110 HC10209990 IC AD8062 HI-SPEED OP-AMP HC10209990
Q111 HC10147090 IC NJM2115V OP-AMP HC10147090
Q112 HC12238090 IC NJM2903V COMPARATOR HC12238090
Q113 HC10147090 IC NJM2115V OP-AMP HC10147090
Q114 HC12238090 IC NJM2903V COMPARATOR HC12238090
Q115 HC010105K0 IC TC74LVX4053FT ANALOG SW HC010105K0
Q116 HC10080250 IC CXD3068Q CD DECODER HC10080250
Q117 HC10222210 IC BA5981FP MOTOR DRIVER-4CH HC10222210
Q118 HC12239090 IC NJM3414AV
DUAL OP-AMP SSOP8P
HC12239090
Q119 HC10427050 IC TC7SHU04F TOSHIBA HC10427050
Q121 HC10209990 IC AD8062 HI-SPEED OP-AMP HC10209990
Q122 HC10156990 IC EM636165TS-7
S-DRAM 2B 16MBYT
HC10156990
Q123 HC10079250 IC CXD2752R SACD DECODER HC10079250
Q124 HC10078250 IC CXD1882R DVD DECORDER HC10078250
Q125 HU01AKY10F MICROPROCESSOR CXPQ71000
CONTROL-UPC
HU01AKY10F
Q126 HC005805K0 IC TC74VHC157FT HC005805K0
Q127 HC10210990 IC M11L16161SA-45T
EDO-DRAM 16M
HC10210990
Q128 BA10014210 DIG.TRS. DTA144EU BA10014210
Q129 BA20021210 DIG.TRS. DTC144EC BA20021210
Q132 HC006105K0 IC TC74VHC541FT HC006105K0
Q133 HC006105K0 IC TC74VHC541FT HC006105K0
Q134 BA20021210 DIG.TRS. DTC144EC BA20021210
Q135 HC007905K0 IC TC7WH74FU D-TYPE FLIP FLOP HC007905K0
Q136 HC010005K0 IC TC7WH08FU
2-INPUT AND GATE
HC010005K0
Q137 HC006105K0 IC TC74VHC541FT HC006105K0
Q138 BA20021210 DIG.TRS. DTC144EC BA20021210
Q139 HC008405K0 IC TC74VHC86FT HC008405K0
Q140 HC009305K0 IC TC74VHC00FT HC009305K0
Q141 HC005605K0 IC TC74VHC74FT D-FF HC005605K0
Q151 HC98A33090 IC NJM2391DL1-33 1A 3.3V HC98A33090
Q152 HC98A33090 IC NJM2391DL1-33 1A 3.3V HC98A33090
Q153 HC98A26090 IC NJM2391DL1-26 1A 2.6V HC98A26090
Q155 HX341161C0 CHIP TRS 2SC4116GR HX341161C0
Q156 HX409992A0 CHIP TRS. 2SD999 CM CL 250 1A HX409992A0
Q157 HX207982A0 CHIP TRS 2SB798 DL DK HX207982A0
Q158 HX341161C0 CHIP TRS 2SC4116GR HX341161C0
Q159 HX409992A0 CHIP TRS. 2SD999 CM CL 250 1A HX409992A0
Q160 HX207982A0 CHIP TRS 2SB798 DL DK HX207982A0
QF01 HU01AKF00F MICROPROCESSOR MB90F553A HU01AKF00F
QF02 HC10098530 IC S-80843ALNP-EA7-T2 4.3V SC82 HC10098530
QF03 BA20021210 DIG.TRS. DTC144EC BA20021210
QF04 HC10033990 IC AT24C04N-10SI-2.5 HC10033990
PV16-MISCELLANEOUS
L101 FC90020100 FERRITE CORE FB M
J2125HM330-T
FC90020100
L102 FC90020100 FERRITE CORE FB M
J2125HM330-T
FC90020100
L103 LU12473010 CHIP INDUCTER 47µH LU12473010
L104 LU12473010 CHIP INDUCTER 47µH LU12473010
L105 LU12473010 CHIP INDUCTER 47µH LU12473010
L109
FC90020100 FERRITE CORE FC90020100
L111 FB M J2125HM330-T
L120
FC90020100 FERRITE CORE FC90020100
L126 FB M J2125HM330-T
L128 FC90020100 FERRITE CORE
FB M J2125HM330-T
FC90020100
L129 FC90020100 FERRITE CORE
FB M J2125HM330-T
FC90020100
L132 FC90020100 FERRITE CORE
FB M J2125HM330-T
FC90020100
L133 FC90020100 FERRITE CORE
FB M J2125HM330-T
FC90020100
X101 JX33001470 CRYSTAL XTAL 33.8688MHZ JX33001470
X103 FQ02005060 SERAMIC VIB. CSTCW-X SMD
20.0MHz
FQ02005060
XF01 FQ08004070 SERAMIC VIB. CSTCC8.00MG-TC
8.000MHz
FQ08004070
PY16-FRONT
CIRCUIT BOARD
PY16-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : ALL
PY16-SEMICONDUCTORS
DY04 HI10062320 L.E.D. LT3D8B RED 3O HI10062320
QY01 HC10416030 IC FL DRIVER LC75712E HC10416030
