Practical hints
Replacing SmartKey batteries
SmartKey
Replacement batteries: Lithium, type
CR 2025 or equivalent.
̈ Remove mechanical key 1
(
୴ page 394).
1 Mechanical key
2 Slide
3 Battery compartment
̈ Insert mechanical key 1 in direction
of arrow in side opening.
̈ Using mechanical key 1, push gray
slide 2 to unlatch battery
compartment 3.
̈ Pull battery compartment 3 out of the
housing in direction of arrow.
̈ Remove the discharged batteries in di-
rection of arrow.
4 Battery
5 Contact spring
̈ Using a lint-free cloth, insert new
batteries 4 under contact spring 5
with the positive terminal (+) facing up.
̈ Return battery compartment 2 into
the housing until it locks into place.
̈ Slide mechanical key 1 back into the
SmartKey.
̈ Check the operation of the SmartKey.
