MT-74F — OPERATION AND PARTS MANUAL — REV. #12 (11/08/07) — PAGE 33
MT-74F — TANK AND HANDLE ASSY.
TANK AND HANDLE ASSY. (NEW VERSION)
NO PART NO PART NAME QTY. REMARKS
1 361117750 HANDLE .................................................. 1 ................S/N L1292 AND ABOVE
2-1 955200052 ROLLER, W/ PIN, SET 1
3-1 091005025 SCREW 5X25 4
4 022610505 FLANGE NUT 4
5 351319900 SHOCK ABSORBER 2
6-1 014210020 SOCKET HEAD BOLT 10X20T ............... 4 ................REPLACES 001521020
6-2 033121009 TOOTH LOCKED WASHER BM10 4
7 012210020 BOLT 10X20 H, SW ................................ 4 ................REPLACES 002211020
9-1 361116910 FUEL TANK 1
12 011208030 BOLT 8X30 T ........................................... 2 ................REPLACES 001220830
13 022710809 NYLON NUT M8 2
14 030208200 WASHER, SW M8 2
15 952401450 WASHER 8.5X22X3 ................................ 2 ................REPLACES 953405640
16 954300720 FUEL COCK ASSY ................................. 1 ................S/N L1292 AND ABOVE
16-4 353432250 CAP 1
17 351437785 HOLDER, FUEL COCK 1
18 954406020 PACKING, FUEL TANK ........................... 1 ................S/N M2535 AND ABOVE
20 954406420 HOSE BAND 10.5 2
21 954406010 STRAINER 1
22 361910070 CAP ASSY, TANK ................................... 1 ................S/N M2535 AND ABOVE
INCLUDES ITEMS W/
*
22-1
*
361455740 SUB CAP 1 S/N M2535 AND ABOVE
22-2 920208960 TAG, GASOLINE 1 S/N M2535 AND ABOVE
28
*
353449010 STRAP, FUEL TANK CAP 1
29 009110014 SCREW, PAN HEAD 8X10 2
30 031105080 PW M5 4
42 351435160 FUEL HOSE B-95 1
43 351436350 FUEL HOSE R-150L D8 1
44 301420730 HOSE BAND ........................................... 2 ................. REPLACES 954403030
45 301419750 FUEL FILTER CP, MQ75MIC. 1
