- 14 -
8. Priority Tag Define the 802.1p tag mapping and the
service rule. Please refer to section 4.13
for detail.
4. User
Authentication
This menu allows you to configure the
password of root, admin and guest
account. Only root account has the right
to enter this menu.
1. System Restart Restart the switch. Two options are
available: cold start and warm start.
2. Default Factory Reset
Reset the switch back to factory default
settings.
3. Timeout Interval Setup
Configure the telnet timeout interval.
4. TFTP Download Update the firmware through TFTP
server.
5. Local Transfer Transfer the firmware from master switch
to slave switch.
6. Ping Ping a IP to test the connection status.
5. System Utility
7. Search Location by
Port Name
Input a port name to get the
correspondence of Device ID and Port
number.
6. Save Runtime
Configuration
Save the configuration you have make on
the switch.
