OPERATION
Operation Section 4-4
OPERATION
© 2004 Alamo Group Inc.
FL14/FL20 10/03
Standard Equipment and Specifications
Horsepower Required (Min.)....... 75 HP 75 HP
Cutting Capacity (Diameter)........2-1/2” 2-1/2”
Cutting Height............................3/4”-12” 3/4”-12”
Safety Deflectors*.......................Standard Standard
Cutting Width............................240” 162”
Transport Width.........................105” 106”
Overall Width.............................248” 170”
Overall Length............................203” 203”
Blade Overlap.............................6” 6”
Weight (Approximate)................ 6465 lbs. 6361 lbs.
Wing Lift....................................Hydraulic Hydraulic
Wing Flex (Degrees)..................90° Up-22° Down 90° Up-22° Down
Jack Stand............................... Standard Standard
Hitch........................................Clevis Clevis
Blade Carrier..............................Pan or Bar Pan or Bar
Gearbox Rating:**
Power Divider.......................200 HP 200 HP
Center & Wings...................150 HP 150 HP
Output Shaft Diameter............... 2” 2”
Blade Tip Speed
540 RPM............................ 16,328 FPM 16,328 FPM
1000 RPM...........................15,994 FPM 15,994 FPM
Driveline Size:
Main.................................. Cat 5 Cat 5
Wings................................ Cat 5 or Cat 6 (1000 RPM) Cat 5 or Cat 6 (1000 RPM)
Deck Thickness........................ 10 Gauge 10 Gauge
Side Skirts............................... 1/4”x10-1/2” 1/4”x10-1/2”
Replaceable Skid Shoes............ Standard Standard
*Safety Deflectors are standard equipment. Single and double chain guards are available as
extra equipment at extra cost. Servis-Rhino recommends mowers be equipped with deflectors
or double chain guards for all mowing purposes. Single chain guards may be used for agriculture
purposes only and are specifically not recommended for highway, right-of-way, parks or greenbelt
mowing.
**Ratings based on actual field performance.
FL20 FL14
