HDC-1000/1400/1450/1500/1550 Specifications
HDC-1000 HDC-1400 HDC-1450 HDC-1500 HDC-1550
General
Power requirements
240 V AC, 1.7 A (max.),
180 V DC, 0.9 A (max.),
12 V DC, 10 A (max.)
240 V AC, 1.4 A (max.),
180 V DC, 1.0 A (max.),
12 V DC, 7 A (max.)
180 V DC, 1.0 A (max.),
12 V DC, 7 A (max.)
240 V AC, 1.4 A (max.),
180 V DC, 1.0 A (max.),
12 V DC, 7 A (max.)
180 V DC, 1.0 A (max.),
12 V DC, 7 A (max.)
Operating temperature -20 °C to +45 °C (-4 °F to +113 °F)
Storage temperature -20 °C to +60 °C (-4 °F to +140 °F)
Mass 21 kg (46 lb 5 oz) 4.5 kg (9 lb 15 oz) 4.9 kg (10 lb 13 oz) 4.5 kg (9 lb 15 oz) 4.9 kg (10 lb 13 oz)
Camera
Pickup device 3-chip 2/3-inch type CCD
Effective picture elements (H x V) 1920 x 1080
Signal format
1080/50i, 59.94i, 23.98P,
24P, 25P, 29.97P50P, 59.94P
1080/50P*, 59.94P*
720/50P, 59.94P
1080/50i, 720/50P
1080/50i, 59.94i, 23.98P,
24P,25P, 29.97P50P, 59.94P
1080/50P*, 59.94P*
720/50P, 59.94P
1080/50i, 59.94i, 23.98P,
24P, 25P, 29.97P
720/50P, 59.94P
Spectrum system F1.4 prism system
Lens mount Sony hanger mount Sony bayonet mount
Built-in filters
CC
A: CROSS, B: 3200K,
C: 4300K, D: 6300K,
E: 8000K
— A: CROSS, B: 3200K, C: 4300K, D: 6300K, E: 8000K
ND
1: CLEAR, 2: 1/4ND,
3: 1/8ND, 4: 1/16ND,
5: 1/64ND
1: CLEAR, 2: 1/4ND, 3: 1/16ND, 4: 1/64ND, 5: CROSS 1: CLEAR, 2: 1/4ND, 3: 1/8ND, 4: 1/16ND, 5: 1/64ND
Sensitivity (at 2000 lx, 3200K,
89.9% reflectance)
F10 (1080/59.94i), F11(1080/50i)
Signal-to-noise ratio (1080i) 54 dB
Horizontal resolution (1080i) 1000 TV lines (at center)
Registration Within 0.02% (all zones, without lens)
Shutter speed selection
1/100, 1/125, 1/250, 1/500,
1/1000, 1/2000 s (1080/59.94i)
1/60, 1/125, 1/250, 1/500,
1/1000, 1/2000 s (1080/50i)
1/60, 1/125, 1/250, 1/500, 1/1000, 1/2000 s
1/100, 1/125, 1/250, 1/500, 1/1000, 1/2000 s (1080/59.94i)
1/60, 1/125, 1/250, 1/500, 1/1000, 1/2000 s (1080/50i)
Modulation depth (1080i) 45% horizontally (typical) (800 TV lines at center, 27.5 MHz, with typical lens)
Input/output connectors
Audio input (CH1)
XLR-3-31 type (male) (1),
mic or line selectable
XLR-3-pin (female) (1), mic or line selectable
Audio input (CH2)
XLR-3-31 type (male) (1),
AES/EBU or mic or line
selectable
XLR-3-pin (female) (1),
AES/EBU or mic or line
selectable
XLR-3-pin (female) (1),
mic or line selectable
XLR-3-pin (female) (1),
AES/EBU or mic or line
selectable
XLR-3-pin (female) (1),
mic or line selectable
Mic 1 input — XLR-3-pin (female) (1)
Return control input 6-pin (1)
Prompter output/Genlock input/
Return input
— BNC type (1), 1.0 Vp-p, 75 Ω
Prompter — BNC type (1), 1.0 Vp-p, 75 Ω —
Prompter 1 BNC type (1), 1.0 Vp-p, 75
Prompter 2 BNC type (1), 1.0 Vp-p, 75 BNC type (1), 1.0 Vp-p, 75 Ω —
DC input XLR-4-pin (1), 10.5 to 17 V DC
DC output 4-pin (1), 10.5 to 17.5 V DC, 500 mA (max.)
Test output BNC type (1), 1.0 Vp-p, 75Ω
SDI 1 output BNC type (2) HD-SDI — BNC type (2) HD-SDI —
SDI 2 output
BNC type (2) HD-SDI or
SD-SDI selectable
(without embedded audio)
—
BNC type (2) HD-SDI or
SD-SDI selectable
(without embedded audio)
—
SDI output —
BNC type (1) HD-SDI or SD-SDI selectable (without
embedded audio)
—
BNC type (1) HD-SDI or
SD-SDI selectable (without
embedded audio)
Earphone output — Stereo minijack (1)
CCU Electro-optical connector (1) — Electro-optical connector (1) —
HDCU/HDFX — Triax connector (1) —
Tracker 10-pin (1)
Crane 12-pin (1)
Intercom 1 XLR-5-pin (female) (1)
Intercom 2 XLR-5-pin (female) (1)
Remote 8-pin (1)
Lens 36-pin (1) 36-pin (1)
Viewfinder D-sub 25-pin (1) (CRT) 20-pin (1) (LCD and Monocle)
Supplied accessories
Angle adjustment brackets
(2), Front cover (1), Num-
ber plates for side panel
(2 sets), Number plates
for up-tally lamp (1 set),
Cable clamp (2),
Operation manual (1)
Operation manual (1), Switch label 1, 2 (1 each)
MSU-900/950 Specifications
MSU-900 MSU-950
General
Power requirements 100 to 240 V AC, 50/60 Hz
Current consumption 0.35 A
Operating temperature +5 to +40 °C (+41 to +104 °F)
Maximum cable length 200 m (656 feet)
Mass 4.5 kg (9 lb 14 oz) 3.7 kg (8 lb 2 oz)
Dimensions (W x H x D) 482 x 67 x 222 mm (19 x 2 3/4 x 8 3/4 inches) 204 x 354 x 67 mm (8 1/8 x 14 x 2 3/4 inches)
Inputs/outputs
Remote
CCU/CNU: 8-pin (1)
AUX: 8-pin (1)
I/O port 50-pin (1)
Ethernet
6-pin (1)
AC input 3-pin (1)
HDLA-1500/1505/1507 Specifications
HDLA-1500 HDLA-1505 HDLA-1507
General
Power requirements 240 V AC (max. 1.2 A)/180 V DC (max. 0.65 A), 12 V DC (max. 9 A)
Operating temperature -20 °C to +45 °C (-4 °F to +113 °F)
Storage temperature -20 °C to +60 °C (-4 °F to +140 °F)
Mass 18.5 kg (40 lb 13 oz) 17.1 kg (37 lb 11 oz) 15.5 kg (34 lb 3 oz)
Input/output connector
Lens 36-pin
DC IN XLR-4-pin (1), 10.5 to 17 V DC
DC OUT
4-pin (1), 10.5 to 17 V DC, max. 1.5 A
Viewfinder D-sub 25-pin (1) (CRT) Camera-mounted LCD D-sub 25-pin (1) (CRT)
