A major reason for this popularity is the wide
range of system parts which allow customers
to configure an HD camera system for
almost any application they require. These
parts include a selection of viewfinders, two
Camera Control Units, six Remote Control
Panels as well as comprehensive connec-
tivity and control options and interfaces for
Hybrid Fibre and Triax cabling. The innova-
tive Large Lens and CRT adapters allow a
portable camera to be docked with Studio
peripherals almost instantly. No re-cabling
or adjustment is required thanks to the ca-
mera ‘hot-shoe’ electrical interface and
lens registration features.
No less important is the ability to capture
superb images in all world wide standards,
both progressive and interlaced, in 1080 or
720 formats and at multiple frame rates.
The amazing picture quality achieved
by this new camera system is due to the
development of an improved CCD and a
completely new Digital Signal Processing
LSI. The CCD is capable of capturing full HD
resolution (1080 x 1920) images at up 60
progressive frames per second in the normal
camera and 180 interlaced frames per
second in the unique, 3 x slow motion
camera. The DSP in turn allows the camera
operator unparalleled freedom of control
over the ‘look’ of the images without
unwanted side effects. New user functions
include multi matrix and variable black
gamma.
Sony HDC cameras are manufactured in our
dedicated factory in Pencoed – South Wales, to the
highest environmental standards.
Please see
http://www.sony.net/SonyInfo/Environment/activities/index.html
for more information
Studio Camera Large Lens/Viewfinder Adaptor
Portable Cameras
HDLA-1507
(for HDVF-700A/9900)
HDC-1000
Optical-fibre interface
1080/50i, 59.94i
1080/23.98P, 24P, 25P, 29.97P
1080/50P*, 59.94P*
720/50P, 59.94P
HDLA-1505
(for HDVF-C950W/C730W)
HDLA-1500
(for HDVF-700A/9900)
HDC-1500
Optical-fibre interface
1080/50i, 59.94i
1080/23.98P, 24P, 25P, 29.97P
1080/50P*, 59.94P*
720/50P, 59.94P
HDC-1550
Triax interface
1080/50i, 59.94i
1080/23.98P, 24P, 25P, 29.97P
720/50P, 59.94P
HDC-1450
Triax interface
1080/50i
720/50P
HDC-1400
Optical-fibre interface
1080/50i
720/50P
The Sony HDC-1000 system camera family is based on more than 20 years of development
of HD TV systems and has been the first choice for literally hundreds of broadcasters for both studio
and OB applications. Many thousands of HDC-1000 systems have been sold around the world
since the introduction in 2005 and the family has continued to improve and grow since then.
Recent additions include the acclaimed HDC-3300 Slow-motion system (in a separate brochure) and
the HDC-1400 and HDC1450 dual format cameras.
3
* 1080/59.94P and 1080/50P signals can be output only from the HDC-1000/HDC-1500 camera head in a stand -alone configuration.
