01
L2 Managed Switch
TP-LINK JetStream L2 Managed Switch, designed for workgroups and departments,
provides wire-speed performance and abundant layer 2 management features. It
provides a variety of service features and multiple powerful functions with high security.
The EIA-standardized framework and smart configuration capacity can provide flexible
solutions for a variable scale of networks. ACL, 802.1x and Dynamic ARP Inspection
provide robust security strategies. QoS and IGMP snooping/filtering optimize voice and
video application. Link aggregation (LACP) increases aggregated bandwidth, optimizing
the transport of business critical data. SNMP, RMON, WEB/CLI/Telnet Log-in bring
abundant management policies. TP-LINK JetStream L2 Managed Switch integrates
multiple functions with excellent performance, and is friendly to manage, which can
fully meet the need of the users demanding higher networking performance.
TL-SG3424P Managed PoE Switch is also a Power Sourcing Equipment (PSE*). All
the Auto-Negotiation RJ45 ports on the switch support Power over Ethernet (PoE*)
function, which can automatically detect and supply power with those powered devices
(PDs*) complying with IEEE 802.3af and IEEE 802.3at.
*PSE: a device (switch or hub for instance) that will provide power in a PoE setup.
*PoE: This technology describes a system to transmit electrical power, along with data,
to remote devices over standard twisted-pair cable in an Ethernet.
*PD: a device powered by a PSE and thus consumes energy. Examples include
powering IP telephones, wireless LAN access points, network cameras, network hubs,
embedded computers etc.
Front Panel
■
The front panel of TL-SG3210 is shown as the following figure.
LEDs
Console Port
10/100/1000Mbps RJ45 Port
SFP Port
Front Panel of TL-SG3210Figure 1-1
Introduction
