Setting Up Your SC-T35
Positioning Your SC-T35
Step 2: Understand Your Stand / VESA Mount Kit for SC-T35
The stand for your SC-T35 is dual-purpose: it can be used as a stand or as a VESA mount kit. All screws of dierent
types supplied with the stand / VESA mount kit can be stored away inside the main bracket when not needed.
Screws Stored Away inside the Bracket
The following gure shows dierent types of screws stored away inside the main bracket.
Screw Type Number Description
12
The largest-size screws used to secure the bracket to a monitor as a VESA mount
LIWKHPLGGOHVL]HVFUHZVFDQQRW¿UPO\VHFXUHWKHEUDFNHWDQG\RXU6&7WRWKH
monitor.
24
The middle-size screws used to secure the bracket to your SC-T35 and to a monitor
when using the bracket as a VESA mount.
3 1 The smallest-size screw used to secure the bracket to your SC-T35 as a stand.
Mount Holes on the Bracket
Refer to the following gure and descriptions for the VESA mount holes on the bracket.
Mount Hole Description
1 The VESA mount holes used to secure the bracket to a monitor (only two of them will be used).
2
The VESA mount holes used to secure the bracket to your SC-T35 (only two of them will be
used).
1
2
1
2
Dual-purpose
bracket
1
2
1
2
1
2
1
2
