Other Information
Other Information
Specifications
CRT Type 19" (18.0" viewable diagonal area),
0.22 mm (H), 0.14 (V), 0.26 (D) dot pitch 90°
deflection, Phosphor RGB, medium short
persistence
Glass surface Anti-reflective and anti-glare coating
Standard light transmission rate = 49.8%
Input Signal Video RGB analog (0.7 Vp-p, 75 ohms),
Sync f
h
: 30-95 kHz, f
v
: 50-180 Hz, H/V Separate (TTL),
Compatibility PC Up to 1280 x 1024 NI
Macintosh
®
*
1
Power Macintosh
®
Maximum Refresh 640 x 480 NI @180 Hz
Rates
*2
800 x 600 NI @ 149 Hz
1024 x 768 NI @ 118 Hz
1280 x 1024 NI @ 90 Hz
1600 x 1200 NI @ 77 Hz
Power Voltage AC 100-240 VAC (auto switch) 50-60 Hz
Display Area Factory setting 300 mm (H) x 225 mm (V) typ
Full scan 320mm (H) x 240 mm (V)
Operating Temperature 32°F to 104°F (0°C to 40°C)
Conditions Humidity 5% to 95% (no condensation)
Altitude To 10,000 feet
Storage Temperature -40°F to +140°F (-40°C to +60°C)
Conditions Humidity 5% to 95% (no condensation)
Altitude To 40,000 feet
Dimensions Physical 466mm (W) x 481mm (H) x 480mm (D)
(monitor) 18.3" (W) x 18.9" (H) x 18.9" (D)
Weight Net 20 kgs (44.1 lbs) Monitor only
Regulations UL, CUL, DHHS, FCC-B, CE, EPA
ENERGY STA R
®
, DOC-B, CB, MPRII
Power saving On <110W (green LED)
modes DPMS
TM
Suspend <15W (orange LED)
DPMS Off <3W (blinking orange LED)
*
1
Macintosh computers requires a ViewSonic
®
Macintosh
adapter. To order an adapter, send an email to
vsparts @ viewsonic.com or call ViewSonic Customer Support. See the back cover. You will need to
provide your monitor's serial number.
*
2
Warning: Do not set the graphics card in your computer to exceed these maximum refresh rates.
Doing so may result in permanent damage to the monitor. NI= Non Interlaced.
VGA 640 x 400 NI @ 70Hz
VESA 640 x 480 NI @ 60, 75Hz
VESA 800 x 600 NI @ 75, 85Hz
VESA 1024 x 768 NI @ 60, 75Hz
VESA 1024 x 768 NI @ 85Hz
Preset Timing Modes (Pre-adjusted to VESA
®
1024 x 768 @ 75Hz)
VESA 1280 x 1024 NI @ 75Hz
VESA 1280 x 1024 NI @ 85Hz
VESA 1600 x 1200 NI @ 75 Hz
Macintosh 832 x 624 NI@ 75Hz
Macintosh 1152 x 870 NI@ 75Hz
