DIAL PLAN (T1 NETWORK AND DUAL/QUAD T1/PRI MODULES)
All menu items in this section (listed as T1/PRI) apply to T1 Network and Dual/Quad Module interfaces
configured in the
DIAL PLAN.
DIAL PLAN (T1/PRI) > NETWORK TERM (PRI)
Write security: 3; Read security: 5
This menu allows the user to define option parameters for ports which terminate a PRI connection from the
network.
DIAL PLAN (T1/PRI) > NETWORK TERM (PRI) > IFCE CONFIG (PRI)
Write security: 3; Read security: 5
Specifies the configuration parameters for the endpoint.
DIAL PLAN (T1/PRI) > NETWORK TERM (PRI) > IFCE CONFIG (PRI) > SWITCH TYPE
Write security: 3; Read security: 5
Defines the type of PRI switch to which the port is connected. If connected to another ATLAS 550, both need to
be set to the same switch type. The following options are available:
DIAL PLAN (T1/PRI) > NETWORK TERM (PRI) > IFCE CONFIG (PRI) > FIRST DS0
Write security: 3; Read security: 5
Defines the first DS0 for this endpoint.The ATLAS 550 uses DS0s, starting with this selection, to send and
receive calls to and from the network. The outgoing calls which are allowed or restricted over these DS0s are
set by
OUT#ACCEPT (see Dial Plan > Network Term > Out#Accept on page 254) and OUT#REJECT (see Dial
Plan > Network Term > Out#Rej on page 256).
DIAL PLAN (T1/PRI) > NETWORK TERM (PRI) > IFCE CONFIG (PRI) > NUMBER OF DS0S
Write security: 3; Read security: 5
Specifies the number of DS0s ATLAS 550 uses for this endpoint.
• Lucent 5E • National ISDN
• Northern DMS 100 • AT&T 4ESS
