ATLAS 550 System Manual Section 4, User Interface Guide
61200305L1-1F © 2002 ADTRAN, Inc. 307
selected routing option. For each case, CALL PARAMS contain OUTDIAL#, CALLER ID, SOURCE ID, and
M
IN/MAX DS0S, as described above.
DIAL PLAN (CKT BACKUP - CIRCUIT BACKUP ENDPOINTS)
DIAL PLAN (CKT BACKUP) > USER TERM
Write security: 3; Read security: 5
This menu allows the user to define option parameters for ports configured as backup endpoints.
DIAL PLAN (CKT BACKUP) > USER TERM > IFCE CONFIG
Write security: 3; Read security: 5
Specifies the configuration parameters for the endpoint.
DIAL PLAN (CKT BACKUP) > USER TERM > IFCE CONFIG > ORIGINATE/ANSWER
Write security: 3; Read security: 5
The following selections are available for the ORIGINATE/ANSWER menu item:
DIAL PLAN (CKT BACKUP) > USER TERM > IFCE CONFIG > OUTGOING CALL TYPE
Write security: 3; Read security: 5
This only applies to originating endpoints.
DIAL PLAN (CKT BACKUP) > USER TERM > IFCE CONFIG > SOURCE ID
Write security: 3; Read security: 5
Simplifies the creation of a dial plan in applications where the criterion for switching calls to a certain
endpoint is a function of which endpoint originated the call.
DEFAULT VALUE = 0. Zero is the default ID for all endpoints and accept numbers. With default values,
all calls are routed based only on the dialed number.
Multiple endpoints can have the same
SOURCE ID.
When creating the
CALL ACCEPT list, specify a SOURCE ID(s) as well as a dialed number or range of
dialed numbers to accept.
DIAL PLAN (CKT BACKUP) > USER TERM > IFCE CONFIG > OUTDIAL NUMBER
Write security: 3; Read security: 5
This only applies to originating endpoints. This is the number dialed when the endpoint goes into backup.
O
RIGINATE The endpoint will originate the backup call.
A
NSWER The endpoint will answer any incoming calls, but will only go into
backup if an error is detected.
A
NSWER ANY The endpoint will answer any incoming calls and go immediately into
backup.
