Changing the output volume level
Users can set the volume level for each local audio output volume
level from the I/O Settings page. Volume is adjustable through a range
of zero steps of attenuation (full attenuation, minimum volume) to
64 steps of attenuation (no attenuation, full volume).
Change the audio volume setting for an output as follows:
1. Click the Volume drop box for the desired output. A drop-down
scroll box appears.
2. Click and drag the slider or click on the scroll up button or the
scroll down button until the desired value is visible.
NOTES: • As an alternative to steps 1 and 2, or to listen to
the audio as you make adjustments, click on the up
button or down button.
• Table 8, on the on the next page, defines the value
of each audio volume step.
Muting and unmuting an audio or RS-232 output
Mute and unmute an audio or RS-232 output by clicking the
associated Audio Mute button. Each click toggles the mute status.
MTPX Plus Series • HTML Operation 143
