Ethernet Icon Tasks
The following sections appear in this chapter:
• “Viewing Bridge Groups” on page 61
• “Viewing Bridge Subnets” on page 64
• “Viewing Bridge Forwarding” on page 64
• “Viewing Redundancy Groups” on page 65
• “Viewing Trunk Groups” on page 66
Viewing Bridge Groups
To view the bridge groups on your Server Switch:
1. Expand the Ethernet icon in the Tree frame.
2. Click the Bridge Groups branch. The Bridge Groups table appears in the View frame. Table 6-1
lists and describes the fields in this table.
Table 6-1: Bridge Groups Table Fields
Field Description
ID Bridge group ID number.
Name Bridge group name.
Subnet Prefix Subnet prefix of the bridge group.
Ethernet Port Displays the trunk group and ports available that the bridge group uses to
connect to the Ethernet switch.
IB Port Displays the internal gateway slot#/port# that is associated with the
bridge-group.
