LaserJet 4100DTN
HP Parts Reference Guide™
www.h
.com/
o/h
arts
External Case Parts
Button
72
RB1-8849-030CN Power switch button
Clip
73
RB1-8860-000CN Right side panel retainer clip
Cover
74
RB1-8858-000CN Formatter board cover panel
75
RB2-4827-000CN Duplexer cover
76
RG5-2664-070CN Right front cover assembly
77
RG5-5098-000CN Left side cover assembly - Includes panel retainer clip
Tray
78
RG5-5097-000CN Drop down rear output tray - Includes pull-out extension
Fusing Assembly Parts
Fusing Assembly
79
C8049-69013 Fusing assembly - 110 volts
REQUIRES RETURN OF DEFECTIVE PART
RG5-5063-340CN New Part for C8049-69013
80
C8049-69014 Fusing assembly - 220 volts
REQUIRES RETURN OF DEFECTIVE PART
RG5-5064-340CN New Part for C8049-69014
RG5-5063-340CN Fusing assembly - 110 volts
Heating Roller
RG5-5068-090CN Fusing roller - Heating element and film sleeve - 110V
RG5-5069-090CN Fusing roller - Heating element and film sleeve - 220V
Roller
RB2-4927-020CN Fuser assembly delivery roller
RB2-4937-000CN Fusing assembly pressure roller
Internal Components
Actuator
86
RB1-8756-000CN Toner cartridge drive rod
87
RB1-8851-000CN Power switch actuator rod
Antenna
88
RG5-5273-000CN Antenna assembly
Arm
89
RB1-8700-000CN Laser shutter arm
Bracket
90
RB2-5008-000CN Cartridge memory antenna mounting bracket (support plate)
Cable
91
RG5-3711-000CN Optical sensor cable
92
RG5-5341-000CN Tray 1 sensor cable
93
RG5-5343-000CN Paper feed and tray 1 pickup solenoid cable
94
RG5-5344-000CN Envelope feeder cable with connector
95
RG5-5345-000CN Top cover switch cable
96
RG5-5346-000CN Main motor cable
97
RG5-5348-000CN Cable assembly - A 7 pin (F) connector to both a 27.9cm (11 inch) cable with a 4 pin (F) connector and a 36.8cm (14.5
inch) cable with a 3 pin (F) connector
