Logic/Control Electronics
PC Board
142
C8049-69009 Engine controller board - Provides all power supply and motor control functions, including power switch - 110 volts -
Does not include insulator sheet or bottom metal plate
143
C8049-69010 Engine controller board - Provides all power supply and motor control functions - 220 volt - Does not include insulator
sheet or bottom metal plate
REQUIRES RETURN OF DEFECTIVE PART
RG5-5360-050CN New Part for C8049-69010
144
RG5-2673-000CN Feeder controller board - Paper Size detection
RG5-5359-060CN Engine controller board - Provides all power supply and motor control functions, including power switch - 110 volts -
Does not include insulator sheet or bottom metal plate
146
RG5-6996-000CN Cartridge memory controller board - Between ECU and the toner cartridge memory antenna
Other Accessories
Cartridge
C8061-67901 Black toner (EP) cartridge - With 'Micro-Fine' toner - Has standard capacity toner - Prints approximately 6,000 pages
C8061-67902 Black toner (EP) cartridge - With 'Micro-Fine' toner - Has maximum capacity toner - Prints approximately 10,000 pages
Cleaning Supplies
5090-3379 Toner cleaning cloth - Specially treated cloth for absorbing toner (1 per package) - Ideal for clening up toner spills
IR Assembly
C4103-67901 FIR pod - Fast infrared reciever - With cable that plugs into formatter board port on back of printer
Manual
5851-1891 LaserJet quick reference service guide (monochrome) - Covers the LaserJet
1000,1100,1300,2300,3300mfp,4100mfp,4200,4300,5000,5100,8150 and 9000 series printers
C8049-90925 LaserJet 4100 service manual (English)
Tray
C8056-69001 500-sheet tray/cassette - This is only the tray, does not include feeder or frame that tray goes into
REQUIRES RETURN OF DEFECTIVE PART
C8056-67901 New Part for C8056-69001
C8056A HP LaserJet 4000/4100 500 sheet tray/cassette - Tray only, does not include feeder or frame that tray goes into
Tray Assembly
C8055-67901 500-sheet paper feeder and tray/cassette - This is the frame and tray that the printer sits on top of
C8055A HP LaserJet 4100 500-sheet paper feeder and tray/cassette - This is the assembly frame and tray that the printer sits on
top of
Paper Path Parts
ADF Assembly
C9148-69004 ADF assembly - Does not include ADF input tray
RG5-6549-090CN New Part for C9148-69004
Arm
158
C8049-67904 Left side output kicker
159
RG5-5093-000CN Delivery sensor arm assembly
Coupler
160
C4119-67902 Coupler kit - Contains pickup roller coupler, four paper tray load limit clips and installation instruction sheet
Feed Assembly
161
RG5-5086-000CN Paper feed assembly
Flag
RB2-5034-000CN Paper sensor flag - Arm that triggers PS106
