Internal Components
Paper Pick-Up
124
RG5-5084-040CN Tray 1 paper pickup assembly
Plate
125
RB2-5002-000CN Continuity plate
Sensor
126
WG8-5362-000CN Optical sensor
Spring
127
RB1-8702-000CN Laser shutter spring - Provides tension for laser shutter
128
RB2-4122-000CN Tray 1 hinge spring
129
RB2-4997-020CN Toner cartridge grounding spring
Support
130
RB2-5003-000CN Top cover left side support
Thermistor
131
RH7-7116-000CN Environment temperature detection thermistor - Detects ambient air temperature to determine length of time for fuser
warm up.
Tray
132
RG5-2656-080CN Paper input tray (Tray 1) - Multi-Purpose tray assembly
LaserJet Electronics
Laser/Scanner
133
C8049-69005 Laser/scanner assembly
REQUIRES RETURN OF DEFECTIVE PART
RG5-5100-080CN New Part for C8049-69005
PC Board
C4169-69001 Formatter board assembly
REQUIRES RETURN OF DEFECTIVE PART
C4169-67901 New Part for C4169-69001
Power Cord
8120-8381 Power cord (Flint Gray) - 18 AWG, 1.8m (72 in.) long - Has 90 degree (F) receptacle (For 120V in the USA, Canada,
Latin America, Korea, Taiwan, and Thailand)
Receptacle
136
RG5-5111-000CN AC power receptacle - Connector and housing assembly - 110VAC
137
RG5-5280-000CN AC power receptacle - Connector and housing assembly - 220VAC
Sensor
138
RG5-5275-000CN Registration and feed sensors assembly - Includes PS 102/103
Switch
139
WC4-5139-000CN Top cover interlock access switch
Transceiver
140
RG5-5276-000CN Toner cartridge memory transceiver assembly - Provides communication between memory controller board and toner
cartridge memory
Logic/Control Electronics
Drive (Product)
C2985A 2.1GB hard drive - LaserJet EIO font/print job storage
NO LONGER SUPPLIED
C2985B New Part for C2985A
