Screw Listing
Maintenance and Service Guide C–7
Phillips M2.5×8.0 Screw Locations
Table C-3
Phillips PM2.5×8.0 Screw
Color Qty. Length Thread
Head
Width
Black 26 8.0 mm 2.5 mm 5.0 mm
Where used:
1 One screw that secures the optical drive to the notebook in the battery bay
(documented in Section 5.7)
2 One screw that secures the keyboard to the notebook in the memory
expansion/Mini PCI compartment (documented in Section 5.8)
3 Three screws that secure the top cover to the notebook (two on the front
edge of the notebook, one in the battery bay (documented in Section 5.11)
mm
