29
www.lowrance.com
Engine Interface Sensors
Cabled sensors for top outboard brands
connects engines to NMEA 2000
®
networks to display engine data.
Electronic Probe Sensors
Only Lowrance offers the most NMEA
2000
®
sensors for vital boat data
monitoring, each with a built-in “smart
module,” that’s fully programmable for
greater accuracy in data delivery.
EP-60R Fuel Flow
Congurable, for gasoline only, one per
engine. Sapphire bearing technology
extends life and increases accuracy
even at low ow. Outputs Fuel Flow, Fuel
Used, Trip Fuel Used and Seasonal Fuel
Used data to the network for fuel
management. NMEA 2000
®
certied.
EP-65R Fluid Level
Compatible with standard U.S. and
European sending units and a range of
uids: fuel; fresh, waste or black water;
live well; and oil. Allows calibration for
more accurate uid level readings for
boats with odd-shaped tanks. NMEA
2000
®
certied.
EP-70R Speed
Paddle wheel for speed and distance
display; NMEA 2000
®
certied.
EP-80R Temperature
Congurable sensor for surface water,
livewell, baitwell, cabin and engine room
temp readings, -20ºC to 80ºC (-4º to
176ºF). NMEA 2000
®
certied.
EP-80R TH Temperature
Congurable surface water temp sensor
for thru-hull installation. NMEA 2000
®
certied.
EP-85R Storage Device
Accumulates and stores real-time engine
data of fuel ow messages for up to
three engines connected to a NMEA
2000
®
network for fuel range
calculations and display. NMEA 2000
®
certication pending.
EP-90R Pressure
Outputs pitot speed or engine pressure
readings – boost, coolant, fuel, engine or
transmission oil. 100 psi max. NMEA
2000
®
certication pending.
Yamaha (late model)
Suzuki (DF Series)
Evinrude (E-TEC)
Networking & Digital Gauges
NMEA 2000
®
Network Starter Kit
Here’s how to easily start your own NMEA 2000
®
onboard network, allowing future expansion to
add sensors and displays. NMEA 2000
®
compliant components include two T-connectors,
2-foot cable, 15-foot cable, two terminating
resistors and network power cable.
N2K-EXP-RD-2 124-69
