(Revised 2010-7-2) page 124 of 145
Display List of Configured Static MAC Addresses
To view the list of configure static mac addresses
bridge show staticmac <all|multicast|unicast>
<all|multicast|unicast>
which set of static mac addresses to show
N-TRON/Admin#[1]> bridge show staticmac all
N-TRON/Admin#[2]> bridge show staticmac multicast
N-TRON/Admin#[3]> bridge show staticmac unicast
These are egress filters.
Set Aging Time
Sets the aging time for dynamically learned MAC addresses of the chipset.
bridge set agingtime <aging-time>
aging-time
aging time to be set for stp.
Minimum aging time can be 5 seconds.
Default aging time is 20 seconds.
Maximum aging time is 1000000 seconds.
N-TRON/Admin#[1]> bridge set agingtime 200
Display Current Aging Time
Displays the current aging time.
N-TRON/Admin#[1]> bridge show agingtime
Display Mac Address by port
Displays all the MAC addresses associated with a port.
bridge show macbyport <port-number|all>
port-number
The port number must range between 1 and the maximum number of
ports on the switch.
all
Display MAC addresses for all ports
N-TRON/Admin#[1]> bridge show macbyport 6
Display port by Mac Address
Display the port number to which the mac is associated.
bridge show portbymac <mac-address>
mac-address
Unique unicast mac address.
N-TRON/Admin#[1]> bridge show portbymac 00-a0-ae-60-3a-70
