21
3. Enter the administrator password.
The password entered will be displayed as “∗” marks.
Notes:
• The factory default is “650”.
• To delete a character, press the CLEAR button.
4. Press the CAM (SET) button.
If the password entered is correct, "Baud Rate" setting
form will appear on the LCD.
Notes:
• If the password entered is wrong, “PS·Data Com.
Setup” will appear on the LCD again to reenter the
password.
• You can change the setting item display on the LCD
by rotating the JogDial.
5. Select an item you wish to set up by rotating the
JogDial.
Baud rate
The speed of communication between the system controller
and other system units
Parity bit
The parity bit, added to the data, to perform parity check
(Refer to p. 22 for details.)
Stop bit
The stop bit, added to the last of data, in asynchronous
communication (Refer to p. 22 for details.)
Wait time
The wait time until the data is sent again (Refer to p. 22 for
details.)
Controller group address
(No need for setup) Remain the factory default.
System unit group address
(No need for setup) Remain the factory default.
6. Perform the settings.
Setting procedures differ depends on items. Refer to p.
21 to 23 for how to operate.
7. After you have completed the settings, turn off the
power.
● Baud Rate Setting
1. Select “Baud Rate” by rotating the JogDial.
(Refer to Step 5 in Operation.)
2. Press the CAM (SET) button.
The LCD display will change from the display mode to
the editing mode.
3. Select a desired parameter by rotating the JogDial,
or pressing the + or – button.
You can select the desired parameter from “19200”,
“9600”, and “4800”. The factory default is “9600”.
Note: Conform this parameter to the baud rate of other sys-
tem units. Otherwise, communication will not be estab-
lished between the system controller and system units.
•
PS Data Com. Setup
Sys G—Adr.
•
PS Data Com. Setup
Baud Rate 9600
•
PS Data Com. Setup
Baud Rate 4800
•
PS Data Com. Setup
Wait Time Off
•
PS Data Com. Setup
Admin Password ∗∗∗∗∗
•
PS Data Com. Setup
Baud Rate 9600
•
PS Data Com. Setup
Baud Rate 9600
•
PS Data Com. Setup
Parity Bit None
•
PS Data Com. Setup
Stop Bit 1
•
PS Data Com. Setup
Cnt G—Adr. A
