Available controls and functions
<Main unit>
Shuttle ring clockwise:
Moves to the next page.
Shuttle ring counterclockwise: Moves to the previous
page.
JogDial clockwise or counterclockwise: Changes the
selected parameter.
+ button: Increases a numeric value.
– button: Decreases a numeric value.
Numeric buttons: Enters a numeric parameter.
CLEAR button (WJ-HD300 Series Only): Clears an
entry such as a password.
Button 0 (WJ-HD300 Series Only): If you enter only "0"
for a parameter, the parameter will be cleared.
CAM (SET) button: Determines the selected parameter
and moves to the sub menu.
MON (ESC) or EXIT button: Returns to the upper
menu.
<Joystick unit>
3D joystick upward (
▲): Moves the cursor up.
3D joystick downward (▼): Moves the cursor down.
3D joystick leftward (t): Moves the cursor to the left.
3D joystick rightward (s): Moves the cursor to the
right.
Zoom wheel controller to the right: Moves to the next
page.
Zoom wheel controller to the left: Moves to the previ-
ous page.
Top button: Determines the selected parameter and
moves to the sub menu.
4. Press the F2 button.
The setup menu of selected system unit will be closed,
and “
s” mark will light up beside “Off”.
● VCR/Camera Selection
(WJ-FS416, etc: Available Only for
Switchers Installing Multiplexer
Board)
If a Multiplexer board is installed inside the switcher, you
can activate either VCR playback or camera picture display
on an active monitor.
1. Display “Mux VCR/CAM” sub menu. (Refer to Step 1 to
4 of p. 51 To Recall Menu Functions.)
Note: “s” mark will light up beside the activated set-
ting.
2. Press the F1 or F2 button.
The monitor display will be changed between playback
pictures and live images, and “
s” mark will light up
beside the activated setting.
Available buttons and functions
F1: VCR
Activates VCR playback.
F2: CAM
Activates camera picture display.
Note: If the Multiplexer board is receiving no video
input signal, “
s” mark will light up beside VCR.
● Still Mode
(WJ-FS416, etc: Available Only for
Switchers Installing Multiplexer
Board)
If a Multiplexer board is installed inside the switcher, you
can change the multiscreen monitor display from the mov-
ing mode to the still mode.
1. Display “Mux Still” sub menu. (Refer to Step 1 to 4 of p.
51 To Recall Menu Functions.)
2. Select the camera channel you wish to change to the
still mode by performing either of the following.
• Press the + or – button.
• Enter the camera number with the numeric buttons.
The entered number will appear on the LCD.
Notes:
• To cancel the numeric entry, press the CLEAR but-
ton.
• To activate the still mode for all camera channels or
spot monitor display, skip this step or enter “0”.
Mux VCR/CAM 304
VCR CAM
F1 F2 F3 F4
Mux Still 305
"Input Still CH"
Mux Still ____9
"Enter F1 Button"
Mux VCR/CAM 304
VCR CAM
F1 F2 F3 F4
Mux Still ____0
"Enter F1 Button"
