26
The LCD display of destination system controller(s)
becomes as follows.
Note: If the check sum is not identical, check the con-
nection of all the controllers, and retry the data base
copy.
12. Turn off the power of source and destination system
controllers.
■
PS·Data Operator Password Check
In case operators have forgotten their passwords, the
administrator can check the passwords in the following pro-
cedure.
● Operation
1. Turn off the power.
2. Turn on the power of system controller while
holding down the button 4 and MON (ESC) button.
“Admin Password” will appear on the LCD to enter the
password.
3. Enter the administrator password.
The password entered will be displayed as “∗” marks.
Notes:
• The factory default is “650”.
• If the password entered is wrong, the LCD display
will return to Step 2.
4. Press the CAM (SET) button.
If the password entered is correct, “User ID” and
“Password” of Operator 1 will appear on the LCD while
you are holding down the buttons.
PSD Password Check
Admin Password _____
PSD Password Check
Admin Password ∗∗∗∗∗
No.01 User ID 650
Password 650
5. To search a desired operator, rotate the JogDial.
The user ID and password of Operator 1 to 16 will
appear interchangeably.
6. Turn off the power.
Operator 1 information
Rotate the JogDial.
Rotate the JogDial.
Operator 2 information
Operator 16 information
•
•
Rotate the JogDial.
No.01 User ID 650
Password 650
No.02 User ID 1
Password 12345
No.16 User ID 100
Password 100
Data Base Rx Mode
Completed Sum=1733
