26
AUTOMATIC TWO-SIDED COPYING
(Only on models that support automatic two-sided copying)
On models that support automatic two-sided copying, two originals placed on the document glass can be copied
onto each side of a single sheet of paper. In addition, an RSPF can be used to copy two originals onto one sheet of
paper, or one two-sided original onto two sheets of paper, or one two-sided original onto each side of one sheet of
paper.
Original
Paper Usable paper
Document
glass
One-sided original
Two sides
11" x 17", 8-1/2" x 14",
8-1/2" x 11", 8-1/2" x 11"R,
5-1/2" x 8-1/2"
The bypass tray cannot be
used.
SPF
11" x 17", 8-1/2" x 14",
8-1/2" x 11", 8-1/2" x 11"R,
Special paper and 5-1/2" x
8-1/2" paper cannot be
used.
The bypass tray cannot be
used.
RSPF
One-sided original
Two sides
Two-sided original
One side
Two-sided original
Two sides
To use paper in the bypass tray, make a two-sided copy as explained in "TWO-SIDED COPYING USING THE
BYPASS TRAY" (p.00).
When performing automatic two-sided copying of a one-sided original, or one-sided copying of a two-sided
original, the image on the back can be rotated 180 degrees to reverse the top and bottom (image rotation in
duplex copying). To rotate the image 180 degrees, enable the setting as explained in "IMAGE ROTATION IN
DUPLEX COPYING" (p.00) or in the user programs (p.00), and then follow the steps below. In particular, when
a one-sided portrait original is placed in a horizontal orientation (8-1/2" x 14" or 8-1/2" x 11" size) for two-sided
copying, the top and bottom of the images on the front and back of the paper will be opposite to each other, and
thus this function can be conveniently used to make the top and bottom of the images agree.
Note
1
2
1
2
11" x 17" or 8-1/2" x 14"
size portrait
Orientation of the
placed original
Normal automatic
two-sided copying
If the orientation of
two-sided copying
is changed
The top and bottom of
the images on the front
and back are reversed.
The top and bottom of the
images on the front and
back are the same.
