APPENDIX
9
Scanner Function
* The resolution may be enhanced by the scanner driver depending on the scanned area and amount of memory installed in the
machine. Detailed information can be found in the scanner driver help file.
Type
Flatbed scanner
Scanning method
Document glass / SPF/RSPF
Light source
Cold negative electrode lamp
Resolution*
Basic: 600 dpi, 1200 dpi
Setting range: 50dpi - 9600dpi
Original types
Sheet media, books
Effective scanning area
00" x 00" (00 mm x 00 mm)
Scanning speed
00 scan per minute
Input Data
1 bit or 12 bit
Output Data
1 bit or 8 bit
Scanning colors
Black and white 2 value, Grayscale, Full color
Protocol
TWAIN / WIA (Windows XP only) / STI
Port
USB port (USB 1.1)
USB port (USB 2.0, Dual function board must be installed)
Drop out color
Yes
Supported operating
systems
Windows98/Me
Windows 2000 Professional/Windows XP Home Edition/Professional
(Detailed information can be found in the SOFTWARE SETUP GUIDE)
Void area
Top and bottom edges 00" (2.5 mm) due to scanner driver
00" (3.0 mm)
As a part of our policy of continuous improvement, SHARP reserves the right to make design and specification
changes for product improvement without prior notice. The performance specification figures indicated are
nominal values of production units. There may be some deviations from these values in individual units.
Note
