LOCATING STOVE
laboratory. Installation of this stove must
comply with the latest edition of NFPA 211 for
reduced clearances and/or your local build-
ing code rulings. Use whichever minimum
dimensions are LARGEST.
Continued on next page
Failure to follow these minimum clear-
ance requirements may result in an unsafe
installation and could cause a fire.
8. Th is s tove me et s U.S. Te st Sta nda rd :
UL 1482-2006.
9. Always locate stove to provide a source of fresh
air into the room where the unit is installed.
Failure to do so may result in air starvation of other
fuel burning appliances and the possible develop-
ment of hazardous conditions.
Fig. 7b – Side View
Minimum Clearance Dimensions
from Combustible Surfaces
12"/30.5cm
12"/
30.5cm
CORNER CLEARANCES
Fig. 6 – Top View
Minimum Corner Clearances
from Combustible Surfaces
Fig. 7a – Front View
Minimum Clearance Dimensions
from Combustible Surfaces
CAUTION: REPLACE FIREBRICKS BEFORE FIR-
ING WOODSTOVE. POSITION FIREBRICKS SO
NO GAPS REMAIN BETWEEN BRICKS.
CAUTION: KEEP FURNISHINGS AND
OTHER COMBUSTIBLE MATERIALS AWAY
FROM THE STOVE AND OUTSIDE MINIMUM
CLEARANCES.
