Digitrip Retrofit Kit Installation Components for Westinghouse DB-25 Series Breakers (Continued)
Step Description Style No. Qty. Comment
Step 5 PT Module 6502C82G01 1
(Cont.) PT Module Mounting Parts
.138-32 x .500 Lng. Screw Fil. 2
.138 Flat Washer Stl. 4 Comm. Only
.138 Lock Washer Stl. 2
.138-32 Nut Hex Stl. 2
Ring Terminals (.190, .250, .312, .375, .500 - Each Size) 3
Wire Clamp 2
Step 6 Trip Unit Assembly Mounting Parts
Mounting Bracket R. H. 1
Mounting Bracket L. H. 1
.500-13 x 1.50 Lng. Hex Bolt 2
.500 Flat Washer Stl. 4
.500 Lock Washer Stl. 2
.500-13 Nut Hex Stl. 2
.375-16 x .1.50 Lng. Hex Bolt 2
.375 Flat Washer Stl. 2
.375 Lock Washer Stl. 2
.375-16 Nut Hex Stl. 2
.250-20 x .500 Lng. Screw Sems 2
Step 7 Sensor Harness 1
Sensor Harness Mounting Parts
.164-32 x .500 Lng. Screw Fil. 3
.164 Flat Washer Stl. 6
.164 Lock Washer Stl. 3
.164-32 Nut Hex Stl. 3
Crimp Connector with Insert 2
Grommet Oblong 1
Wire Clamp 3
Step 8 PT Wire Mounting Hardware
.250-20 x .500 Lng. Screw Sems 2
.164-32 x .500 Lng. Screw Fil. 1
.164 Flat Washer Stl. 2 Comm. Only
.164 Lock Washer Stl. 1
.164-32 Nut Hex Stl. 1
Wire Clamp 1
Step 9 Sensor 3 See Pick List
Grommet Oblong 1 From Step 7
