Effective December, 1998
IL 33-FC6-1
Page 16
Digitrip Retrofit Kit Installation Components
for the Federal Pacific 100-HF (Canadian) Breaker (Continued)
Step Description Style No. Qty. Comment
Step 7 .138 Flat Washer Stl. 8
(cont.) .138 Lock Washer Stl. 4
.138-32 Nut Hex Stl. 4
.164-32 × .312 Lng. Screw Pan / Lock 2
.164 Flat Washer Stl. 2
.112-40 × .250 Lng. Screw Fil. 4
.112 Flat Washer Stl. 4
.112 Lock Washer Stl. 4
Digitrip Nameplate 1
Step 8 Trip Unit Assembly (from Step 7) 1
Trip Unit Mounting Parts 4A35663G09 1
.250-20 × .750 Lng Hex Bolt 2
.250 Flat Washer Stl. 4
.250 Lock Washer Stl. 2
.250-20 Nut Hex Stl. 2
Step 9 Trip Finger 4A35663G10 1
Step 10 DTA Reset Assembly 4A35663G11 1
Reset Sub-assembly 1
Loc-Tite
®
242 1
.375-16 × 1.50 Lng. Hex Bolt 1
.375 Flat Washer Stl. 1
.375 Lock Washer Stl. 1
Operator Parts 4A35663G16 1
Operator 1
.190-16 × .500 Lng. Screw Fil. 2 Comm. Only
.190 Flat Washer Stl. 4
.190 Lock Washer Stl. 2
.190-32 Nut Hex Stl. 2
Step 11 Universal DTA 6503C67G11 1
DTA Assembly Parts 4A35663G12 1
Trip “Z” Bar 1
Spring Mercer No. 1
Spacer Brass (10D0135H18) 1
.164-32 × 1.00 Lng. Screw Fil. 1
.164 Flat Washer Stl. Wide 1
.164-32 Nut Hex Stl. 1
.250-20 Nut Hex Stl. 1
Loc-Tite
®
242 1
Pivot Bracket 1
Pivot Pin 1
.188 “X”-Washer Stl. 2
