Effective December, 1998
IL 33-FC6-1
Page 17
Digitrip Retrofit Kit Installation Components
for the Federal Pacific 100-HF (Canadian) Breaker (Continued)
Step Description Style No. Qty. Comment
Step 11 Reset Arm 1
(cont.) .250-20 Flange Nut 1
Mounting Bracket Assembly 1
Barrier 1
.164-32 × .312 Lng. Screw Pan / Lock 6
.164 Flat Washer Stl. 6
Mounting Bracket 1
.190-32 × .500 Lng. Screw Fil. 2
.190 Flat Washer Stl. 4
.190 Lock Washer Stl. 2
.190-32 Nut Hex Stl. 2
Terminal Block 2-Point 1
.138-32 × .625 Lng. Screw Fil. 2
.138 Flat Washer Stl. 4
.138 Lock Washer Stl. 2
.138-32 Nut Hex Stl. 2
Aux. Switch Kit 4A35663G02 1
Microswitch BZ-2RW863-A2 1
Mounting Bracket 1
.138-32 × 1.00 Lng. Screw Fil. 2
.138 Flat Washer Stl. 4
.138 Lock Washer Stl. 2 Comm. Only
.138-32 Nut Hex Stl. 2
.190-32 × .625 Lng. Screw Nylon 2
.190 Flat Washer Stl. 6
.190 Lock Washer Stl. 4
.190-32 Nut Hex Stl. 4
Wire Tie Nylon (from 4A35663G14 Step 13) 1
Step 12 DTA Assembly (from Step 11) 1
DTA Mounting Parts 4A35663G13 1
.250-20 × .750 Lng. Screw Stl. 3
.250 Flat Washer Stl. 3
.250 Lock Washer Stl. 3
.250-20 Nut Hex Stl. 3
Loc-Tite
®
242 1
Step 13 Aux. CT Harness 6502C84G02 1
Sensor Harness Parts 4A35663G14 1
Sensor Harness 1
DTA Extension Harness 1
Wire Tie Nylon 8
PT Extension Harness (from 4A35663G02) 1 Comm. Only
