Configuring a VNX series or CLARiiON boot device for FC or FCoE
161
Configuring a Boot Device on an EMC Storage Array
Configuring a VNX series or CLARiiON boot device for FC or
FCoE
This section describes how to install an EMC-qualified version of
Linux onto an EMC VNX series or CLARiiON storage system
connected to an Intel-based x86 and x86_64 class systems and AMD
Opteron-based x86_64 class systems.
Preparing the VNX series or CLARiiON storage system
To prepare the VNX series or CLARiiON storage system:
◆ It is recommended that Access Logix
™
be enabled on the VNX
series or CLARiiON storage system for LUN masking purposes.
◆ Boot device support requires a Unisphere/Navisphere
Management station with Unisphere/Navisphere Manager or
CLI installed. The station must be separate from the server being
installed and must be networked to the VNX series or CLARiiON.
◆ Before installing Linux onto an EMC VNX series or CLARiiON
system, the array must have one bound LUN allocated to the
Storage Group for the server being installed. The LUN must be
owned by the SP connected to the boot adapter.
◆ During the installation procedure, only one LUN should be in the
boot Storage Group, so that the boot LUN may be identified
easily. After the installation, additional LUNs may be added to
the host's Storage Group.
Note: If LUNs need to be created, refer to the Unisphere/Navisphere
Management software documentation for the array type.
Preparing the host
To prepare the host,
◆ Create a zone that includes the WWPN of the adapter to be used
and one SP port. Add the newly-created zone to the zone
configuration in the fabric and enable the zone configuration.
◆ EMC recommends using port 0 on the SP for consistency.
