Installation
The HP LaserJet 4Si Series and 5Si Series Printers
Have Two Card Slots
The HP LaserJet 4Si, 4Si MX, 5Si, 5Si MX, 5Si NX, and 5Si Mopier
printers have two HP modular input/output (MIO) slots that enable
you to run more than one type of network, such as Ethernet and
Token Ring, by installing a card for each type of network.
Note the following restrictions:
• The use of two Ethernet cards in the same printer (which
includes both 10Base-T or 100Base-TX cards) is
not supported
.
• If you plan to install an HP J4100A 10/100Base-TX JetDirect
card in a LaserJet 5Si Series printer, use the
upper
MIO slot.
• If you plan to install only one card in an HP LaserJet 4Si Series
printer, use the
lower
MIO slot. If you want to add an additional
card in a 4Si Series printer, you must perform special installation
procedures to use the
upper
MIO slot. To use the upper MIO slot,
you must use one of the following HP JetDirect products:
HP J4105A or HP J4106A. The special installation instructions
are described later in this chapter.
NOTE
The HP J4100A 10/100Base-TX JetDirect card is
not supported
in the upper slot of an HP LaserJet
4Si Series printer. If you plan to use this card, you
must install it in the
lower
MIO slot.
