Using the Control Panel for Printers 3-5
3
Printer Control
Panel
Novell NetWare Frame Types
on an HP JetDirect Token Ring Card
To configure a NetWare frame type
NOTE
For HP 2500C/CM Professional Series
and DesignJet ColorPro GA printers, see the
“HP 2500C/CM Professional Series and DesignJet
ColorPro GA Control Panel” instructions at the
end of this chapter.
If you have not already done so, enable Novell NetWare (
IPX/
SPX=ON*
) by following the instructions described in “To enable or
disable network protocols” in this chapter.
1. Take the printer offline by pressing
[On Line]
or
[Go]
to indicate
offline.
2. Press
[Menu]
repeatedly until the following message is displayed
on the control panel:
Frame Type Description
AUTO (default) Automatically senses and limits the frame type to
the one detected.
TR_8022 Limits the frame type to IPX over IEEE 802.2 with
IEEE 802.5 frames. All others will be counted
and discarded.
TR_SNAP Limits the frame type to IPX over SNAP with
IEEE 802.5 frames. All others will be counted
and discarded.
4 Series printers
AUX IO MENU
4 Plus and 4V Series printers
MIO MENU
Color LaserJet printers
(
Proceed to Step 4
)
MIO CONFIG MENU
CFG NETWORK=NO *
4Si Series printers (select the
card slot being configured)
MIO MENU 1
or
MIO MENU 2
5Si Series printers (select the
card slot being configured)
HP MIO 1 MENU
or
HP MIO 2 MENU
5 Series printers
HP MIO MENU
