Illustrations and Parts Lists
8-15
2 RG5-3553-000CN 1 Rear Door Sensor Assembly
3 RG5-3585-000CN 1 Tray 1 Separation Pad with
Spring
4 RH7-5195-000CN 1 Paper Pick Up Solenoid
5 WS6-5092-000CN 1 Power Connector
6 RB2-1782-000CN 1 Paper Sensor Lever
7 RB2-1784-000CN 1 Paper Sensor Lever Spring
8 RB2-1781-000CN 1 Paper Sensor Lever
9 RB2-1783-000CN 1 Paper Sensor Lever Spring
10 RB2-1985-000CN 1 Lower Delivery Roller
11 RB2-1988-000CN 1 Right Bushing Lower Delivery
Roller
12 RB2-1989-000CN 1 Left Bushing Lower Delivery
Roller
13 RS6-0357-000CN 1 Lower Delivery Shaft Gear
14 RH7-5192-000CN 1 Paper Feed Clutch
15 RB2-1734-000CN 1 Grounding Plate
16 RB2-1735-000CN 1 Grounding Plate
17 RB2-1737-000CN 1 Grounding Plate
18 RB1-6141-000CN 1 Grounding Plate
19 RB2-1990-000CN 1 Grounding Plate
23 XA9-0267-000CN 2 M3x6 Screw, TP
24 XB4-7401-007CN 14 M4x10 Screw, Tapping, Pan
Head
25 RB2-1825-000CN 1 Leaf Spring
Table 8-7. Internal Components (1 of 4) (continued)
Item No. Part No. Quantity Description
