7 Problem solving 108
Clearing jams
To clear jams in the left door (fuser area)
1 Move the output device away from the product to gain access to the left door.
2 Open the left door.
WARNING!
Avoid touching the adjacent fusing area. It can be HOT.
3 Remove any jammed or damaged paper from this area by pulling it out of the
product.
4 Press down on the green tab and carefully check for paper. Be sure to remove
all pieces of torn paper.
5 Close the left door. Push the output device back into place.
1
4
5
2
