Slide the cover up and away from the printer.
WARNING: The system board access cover must be replaced before operating the printer.
Locating memory and network options
Use the following illustration to locate the connector for the card you want to remove.
Screws
Screws
Memory and flash memory
card connectors
Option card
connector
Parallel
connector
USB
connector
Ethernet
connector
Optional hard disk
Optional
ImageQuick
firmware card
