EPSON EPL-N2700 Rev. A
Chapter 4 Disassembly/Assembly 103
4.2.12 Toner Empty Sensor Removal
1. Remove the Top Cover. (See Section 4.2.11.)
2. Remove one screw (3504) securing the Toner Empty Sensor to the
printer frame and remove the sensor.
3. Disconnect the harness from the connector on the sensor.
Figure 4-23. Toner Empty Sensor Removal
Harness
Toner Empty Sensor
