EPL-N2700 Revision A
Product Description External Interface Specifications 28
1.3 External Interface Specifications
The EPL-N2700 supports the following interfaces.
Bidirectional parallel I/F (standard)
RS-232C serial (standard)
Ethernet I/F
Type-B interface slot (option)
See Figure 1-4 for the locations of the Interface slots.
Figure 1-4. Interface Slot Location
1.3.1 Host Interface Usage Configurations
The EPL-N2700 has the automatic interface switching mode. however,
the interface to be used can be fixed by a control panel operation.
Ethernet I/F C onnector
S e ria l I/F C o n n e c to r
O ptional TypeB Slot
Parallel I/F Connector
(IEEE1284 B Connector
(1) 100Base/10Base Lam p (C olor: O range)
(2) Link/Reception Lam p (Color: G reen)
(1 )
(2 )
Table 1-19. Host Interface Usage Configurations
Parallel I/F Serial I/F Ethernet I/F Type B I/F
1. Automatic I/F
switching
Usable Usable Usable Usable
2. Fixed I/F
(Parallel)
Usable Not Usable Not Usable Not Usable
3. Fixed I/F
(Serial)
Not Usable Usable Not Usable Not Usable
4. Fixed I/F
(Ethernet)
Not Usable Not Usable Usable Usable
5. Fixed I/F
(Type B I/F))
Not Usable Not Usable Not Usable Usable
