EPSON EPL-N2700 Rev. A
Chapter 4 Disassembly/Assembly 89
4.1.3 Small Parts
The small parts used in the printer are listed in the following table.
Table 4-2. Small Part Classification
Reference No. Size Name Appearance
0208 3
×
10 Spring pin
0214 3
×
20
0242 3
×
18
0245 3
×
18
0509 2
×
12 Pin
0510 3
×
14
0512 2
×
18
0531 3
×
18
0534 1.5
×
6
0535 2.5
×
10
1210 3
×
8 CP with a spring washer
screw
1305 3
×
6 Screw with a spring
washer + plane washer
1308 3
×
8
1309 3
×
10
1322 4
×
14
1379 2
×
4
1421 3
×
8 Flat head screw
1723 3
×
8 Cup screw
2101 3
×
6 Bind screw
2703 4
×
6
3104 3
×
8 Tapping screw
(Pan head B-tite screw)
3114 4
×
6
3211 3
×
14 Tapping screw
(Flat head B-tite screw)
3305 3
×
8 Tapping screw
(Pan head B-tite screw)
3402 3
×
6 Tapping screw
(Pan head S-tite screw)
3435 3
×
30
3501 3
×
6 Tapping screw
(Cup head S-tite screw)
3504 3
×
8
3505 3
×
10
3506 4
×
6
3509 4
×
10
3520 3
×
14
3541 3
×
8
3702 4
×
10 Tapping screw
(Pan head B-tite screw)
3703 4
×
12
3704 3
×
8
3708 3
×
8
3709 3
×
10
3727 3
×
8
Reference No. Size Name Appearance
