Service Calibrations
5-10
HP DesignJets 1050C and 1055CM Printers Service Manual
3 If you selected to continue, then the following message appears on
the front panel if media is not loaded. You must load Media in to the
Printer to continue.
4 The Printer will start to print the Line Sensor Pattern and the
following message will be displayed on the front panel:
5 Once the line sensor calibration is completed, the following
message will be displayed on the front panel:
6 To check if the Calibration was completed correctly, print the
Service Configuration Print (see Page 1-19) and check that the
values given for the LED (Green/Blue) are NOT zero.
7 If the calibration fails Perform the Electronic Systems Test Page
4-5.
perform this operation
Please, load paper to
and try again
Press ENTER to continue
To p
Enter
Back
Press Enter
ACCURACY
Calibrating
Please wait.
Calibrating line sensor.
Press ENTER to continue
To p
Enter
Back
Press Enter
Line sensor calibrated.
Check that these value are NOT zero
