Information Menu 28
The following table describes the SNMPv3 Target Parameters Table information.
Table 15 Target Parameters Table
Field Description
Name Displays the locally arbitrary, but unique identifier associated with this snmpTargeParamsEntry.
MP Model Displays the Message Processing Model used when generating SNMP messages using this
entry.
User Name Displays the securityName, which identifies the entry on whose behalf SNMP messages will be
generated using this entry.
Sec Model Displays the security model used when generating SNMP messages using this entry. The system
may choose to return an inconsistentValue error if an attempt is made to set this variable to a
value for a security model which the system does not support.
Sec Level Displays the level of security used when generating SNMP messages using this entry.
SNMPv3 Notify Table information
Command: /info/sys/snmpv3/notify
Name Tag
-------------------- --------------------
v1v2trap v1v2trap
The following table describes the SNMPv3 Notify Table information.
Table 16 SNMPv3 Notify Table
Field Description
Name The locally arbitrary, but unique identifier associated with this snmpNotifyEntry.
Tag This represents a single tag value which is used to select entries in the
snmpTargetAddrTable. Any entry in the snmpTargetAddrTable that contains a tag
value equal to the value of this entry is selected. If this entry contains a value of zero length, no
entries are selected.
