Hurricane 9200/S ADSL Ethernet Router User’s Guide
34
4
The Quick Start process should enable any computer on your LAN
to use the Hurricane 9200/S to access the Internet.
To test the connection, turn on the device, wait about 30 seconds,
and then verify that its LEDs are illuminated as shown in Table 2.
Table 2. LED Indicators
LED Behavior
Power
Displays solid green to indicate that the device is turned
on.
Ethernet
Displays solid green when the Ethernet connection is up.
Flashes while data is being sent to and received from your
LAN PCs.
ADSL
Displays solid green when the DSL line is up. Flashes
during DSL handshake.
Internet
Flashes while data is being sent to and received from the
Internet.
If the LEDs illuminate as expected, test your Internet connection
from a LAN computer (and from the USB computer, if applicable):
Open your web browser and type the URL of any external website
(such as http://www.yahoo.com). The LED labeled Internet should
be blinking rapidly and may appear solid as the
device
connects to
the site.
If the LEDs do not illuminate as expected or the web page does not
display, see Appendix A for troubleshooting suggestions. Or,
contact your ISP for assistance.
