Hurricane 9200/S ADSL Ethernet Router User’s Guide
40
Figure 10 System View Table
The Home page contains the System View table, which provides a
snapshot of your system configuration. Note that some settings link
to the related pages in Configuration Manager where you can
change the data or view details. The following table describes each
section of the System View table.
Table Heading Description
Device
Displays basic information about the Hurricane
9200/S hardware and software versions, the
system uptime (since the last reboot), and the
preconfigured operating mode.
DSL
Displays the operational status, version, DSL
standard, and performance statistics for the DSL
line. You can click on DSL in the table heading or
display the WAN tab to view additional DSL
settings, which are described in Chapter 16.
DSL
Displays the operational status, version, annex
type, connected standard, data boost, profile and
performance statistics for the DSL line. You can
click on DSL in the table heading or display the
WAN tab to view additional DSL settings, which
are described in Chapter 16.
