• Output #1 on the PC5200/PC5204 Power Supply/Output
Module.
•T-Link Troubles
General System Supervisory Restoral: the General Sys-
tem Trouble Restoral Reporting Code will be transmitted
when the control panel detects all modules enrolled on the
keybus
[347] - Miscellaneous Maintenance Reporting Codes
Telephone Number 1 (2) FTC Restore: if the panel fails to
transmit information to the central station it will display a fail-
ure to communicate trouble condition. The panel will transmit
a Phone Number 1 Failure to Communicate Reporting
Code or a Phone Number 2 Failure to Communicate
Reporting Code the next time it calls the central station. The
panel will transmit the old events, followed by the failure to
communicate, followed by the new events.
Event Buffer 75% Full: if the Event Buffer is uploaded on a
regular basis an Event Buffer 75% Full Reporting Code can
be transmitted to warn that the Buffer is almost full.
NOTE: For EN panels, the Event Buffer 75% Full will not be
logged.
DLS Lead In: the DLS Lead In Reporting Code will only be
transmitted if the DLS Call Back feature is being used (See
Section 5.8 "Downloading"). Before the panel calls the com-
puter back it will call central station and transmit the report-
ing code to indicate a download session is about to begin.
DLS Lead Out: after a downloading session is attempted
and/or completed, the panel will transmit a DLS Lead Out
Reporting Code.
Zone Fault Alarm: the Zone Fault Alarm Reporting Code
will be transmitted when there is a short detected on any
DEOL zone and/or a loss of supervisory on a wireless zone.
Zone Fault Restore: the Zone Fault Restore Reporting
Code will be transmitted when the fault condition on the zone
is corrected.
Delinquency Code: the Delinquency reporting code is sent
whenever the panel is not armed within the number of days
programmed for the Delinquency Transmission Delay.
General Zone Low Battery Alarm: the panel will transmit a
General Zone Low Battery Alarm Reporting Code when a
wireless detector indicates a low battery condition and the
delay programmed in "Zone Low Battery Transmission
Delay" expires.
General Zone Low Battery Restoral: the General Zone
Low Battery Restoral Reporting Code will be transmitted
when the low battery condition on all wireless zones is cor-
rected. The specific zone that caused the trouble will be
stored to the Event Buffer.
[348] - Test Transmission Reporting Codes
Walk Test End: the walk test end reporting code will be
transmitted when a walk test is terminated
Walk Test Begin: the walk test begin reporting code will be
transmitted when a walk test is initiated
Periodic Test Transmission with Trouble - the panel can
be programmed to transmit a Periodic Test Transmission
with Trouble Reporting Code in place of the standard Peri-
odic Test Transmission if any of the following conditions exist.
• Fire Zone Trouble (Zones 1-64)
• Battery Trouble (PC1616/PC1832/PC1864, PC520X)
• Fire Zone Alarm (Zones 1-64, Two-Wire Smoke
• Aux Trouble (PC1616/PC1832/PC1864)
• Fire Trouble (Two-Wire Smoke)
• Bell Trouble (PC1616/PC1832/PC1864)
• Fire Tamper/Low Sensitivity (WLS/AML Zones 1-32)
• Module Supervisory
• Fire Zones Bypassed (Zones 1-64)
• Ground Fault (PC5700)
• Fire Supervisory (Wireless/AML Zones 1-32)
• TLM Trouble (PC1616/PC1832/PC1864, PC5700 Line
1-2)
• AC Trouble (PC1616/PC1832/PC1864, PC520X)
• FTC Trouble
Periodic Test Transmission: the Periodic Test Transmission
Reporting Code will be transmitted at the specified time,
(programmed in Section 378) every X number of days (see
Section 377).
System Test: the System Test reporting code will be transmit-
ted when a system test is performed on the panel.
[349] - PC5700 Maintenance Reporting Codes
PC5700 Ground Fault Trouble: the panel will transmit this
reporting code when a Ground Fault Trouble occurs on the
PC5700.
PC5700 Ground Fault Restore: the panel will transmit this
reporting code when the Ground Fault Trouble condition has
restored on the PC5700.
PC5700 TLM 1(2) Trouble: the panel will transmit this report-
ing code when a TLM Trouble occurs on the PC5700 Line 1
and/or on line 2.
PC5700 TLM 1(2) Restore: the panel will transmit this report-
ing code when a TLM Restore occurs on the PC5700 Line 1
and/or Line 2.
[350] - Communicator Format Options
This section requires 2 two digit entries to set the communi-
cations format that is to be used for each phone number (1
per phone number). The 3rd telephone number uses the for-
mat programmed for the 1st telephone number.
Reporting Codes
• SIA -0 is valid in Account or Rep Code (not 00 in a
Reporting code though)
• ADEMCO Contact ID - 0 is not valid in Account or Rep
Code (A must be used, 10 in checksum)
• BPS Formats - 0 is not valid in Account or Rep Code (A
must be used)
• SIA - This format uses 300 Baud FSK as the communi-
cation media. The Account Code can be 4 or 6 hexadec-
imal digits in length, All reporting codes must be 2 digits
in length. The SIA format will transmit a 4 (or 6) digit
account code, a 2 digit identifier code and a 2 digit
reporting code. The 2 digit identifier is pre programmed
by the panel.
Contact ID
Contact ID is a specialized format that will communicate
information quickly using tones rather than pulses. In addi-
tion to sending information more quickly the format also
allows more information to be sent. For example, rather than
reporting an alarm zone 1 the Contact ID format can also
report the type of alarm, such as Entry/Exit alarm zone 1.
Entry Communication Format
01 20 BPS, 1400 HZ handshake
02 20 BPS, 2300 HZ handshake
03 DTMF CONTACT I.D.
04 SIA FSK
05 Pager
06 Residential Dial
07 10 BPS, 1400 Hz handshake
08 10 BPS, 2300 Hz handshake
09 Private Line
10 Scantronics 4-8-1 Fast Slot
11 For Future Use
12 Robofon
13 CESA 200
