10Ć18 Parts and Diagrams
C4699Ć90000
Bail and Overdrive
Reference
on
Drawing
HP Part Number Quantity Description
1 0624Ć0617 1 Screw 6Ć9 .937 Plast T15
2 0624Ć0745 2 Screw M4 x 10 Tap T20
3 3050Ć0026 1 Washer 3.2 mm
4 C3190Ć40019 1 Cam Gear
5 C1633Ć40027 1 Engaging Gear
6 C3190Ć80013 1 Cable Spring
7 C3190Ć40021 1 Gear Support
8 0510Ć0083 2 Ring Net .250 OD
9 C3190Ć60131 1 Clutch Assembly (Incl. Rings and Bushings)
10 C3190Ć40055 2 Sideplate Bushing
11 C1633Ć20021 1 Shoulder Screw
12 C1633Ć40019 1 Overdrive Gear
13 3050Ć1415 1 Washer Flat
14 0515Ć1743 1 Screw M4 x 17 Tap T20
15 C3190Ć40020 1 BailĆLift Cam
16 0624Ć0704 6 Screw Plas 6Ć19 x 375
