6Ć11 Removal and ReplacementC4699Ć90000
C
CAUTION
In the following step, be careful not to
damage the two electronic cables attached
inside the endĆcover.
6 Pull the endĆcover up.
7 Inside the endĆcover, press the two
indicated tabs towards each other, and
remove the frontĆpanel assembly from the
endĆcover.
8 To be able to easily use the frontĆpanel,
when the right endĆcover has been
removed, slide the frontĆpanel assembly
onto the metal base of the plotter as
shown.
